Small Tunnel X-ray Food Inspection Equipment XR-100D
Juzheng X-Ray Inspection Systems provide high cost-effective contaminants detection for food and pharmaceutical manufacturers.
Leading advantage
- Safety in design
- Easy-of-use
- Simple maintenance
- Low cost & Fast dispatch
- Professional and timely after-sales service
Working principle
The X-ray foreign body detector uses the penetrating ability of X-rays to effectively detect all kinds of metal foreign bodies or non-metal foreign bodies in the product, with higher sensitivity and high stability, helping to effectively improve the quality of the finished product, and not only can detect food ( Foreign objects in meat products, aquatic products, fruits and vegetables, additives, milk powder, chocolate, jelly, etc.), medical treatment, textiles (broken needles, abnormal labels, etc.) can also identify product defects: such as packaging cracks, air bubbles, content defects, etc. Achieve complete finished product inspection.
XR-100D series is used for detecting contaminants inside of the small packaged products. Metal and non-metal impurities include ferrous, non-ferrous, stainless steel, glass, ceramic, stone, bones, had rubber and hard plastic, even for products wrapped in aluminum foil or metallised film and etc. The foreign object is detectable by its density. The greater density they have, the easier they can be found. That is why we normally use X-RAY inspection system to detect even the most tiny contaminants.
The food X-ray machine takes the advantage of the penetrating ability of X-rays to detect dense metals, glass, stones, bones, etc. mixed in the product, to distinguish and extract image information through vision and pattern recognition , discrimination,and then achieve foreign body treatment.And mark the impurities position in the detection images, also sound, light alarm.
Juzheng X-Ray Inspection Systems provide high cost-effective contaminants detection for food and pharmaceutical manufacturers.
Leading advantage
- Safety in design
- Easy-of-use
- Simple maintenance
- Low cost & Fast dispatch
- Professional and timely after-sales service
Working principle
The X-ray foreign body detector uses the penetrating ability of X-rays to effectively detect all kinds of metal foreign bodies or non-metal foreign bodies in the product, with higher sensitivity and high stability, helping to effectively improve the quality of the finished product, and not only can detect food ( Foreign objects in meat products, aquatic products, fruits and vegetables, additives, milk powder, chocolate, jelly, etc.), medical treatment, textiles (broken needles, abnormal labels, etc.) can also identify product defects: such as packaging cracks, air bubbles, content defects, etc. Achieve complete finished product inspection.
XR-100D series is used for detecting contaminants inside of the small packaged products. Metal and non-metal impurities include ferrous, non-ferrous, stainless steel, glass, ceramic, stone, bones, had rubber and hard plastic, even for products wrapped in aluminum foil or metallised film and etc. The foreign object is detectable by its density. The greater density they have, the easier they can be found. That is why we normally use X-RAY inspection system to detect even the most tiny contaminants.
The food X-ray machine takes the advantage of the penetrating ability of X-rays to detect dense metals, glass, stones, bones, etc. mixed in the product, to distinguish and extract image information through vision and pattern recognition , discrimination,and then achieve foreign body treatment.And mark the impurities position in the detection images, also sound, light alarm.
| Model | XR-100D | XR-500D | ||
| Tunnel size(W*H) | 400*180mm | 400*250mm | 500*250mm | |
| X-ray Generator | 60kV,60W | 80kV,160W | ||
| Sensitivity | Stainless steel ball: Φ0.5mm, Ceramic/Glass Ball: Φ 1.5mm | |||
| X-ray direction | From the top | |||
| Conveying speed | 10-32m/min | 10-40m/min | ||
| Screen | 17'' Full touchable screen | |||
| O/S | Windows 10 | |||
| Interface for data | LAN port,USB port | |||
| Working environment | Temperature:-10-40℃(Cooling:industrial cooling fans), | |||
| Humidity:30%-90%,No frost(humidity control:dehumidifier) | ||||
| X-ray leakage | <1µSv/hour | |||
| Protective mode | 4-layer Protective soft curtain (Removable) | |||
| Alarm | Sound and light alarm,conveyor stop | |||
| Rejection system | Optional (Please refer to automatic rejection systems) | |||
| Power supply | AC220V ±10% 50/60Hz,1.5kVA Max | |||
| Material of Construction | SUS304 | |||
| Conveyor load | 2kg | 5kg | ||
